Octal SPI Master IIP

Octal SPI master is full-featured, easy-to-use, synthesizable design, compatible with standard protocol of Macronix (MX66LM1G45G) Octal SPI REV.1.0 specification.Through its octal SPI master compatibility,it provides a simple interface to a wide range of low-cost devices. OCTAL SPI master IIP is proven in FPGA environment.The host interface of the OCTAL SPI master can be AMBA APB, AMBA AHB, AMBA AHB-Lite, AMBA AXI, AMBA AXI-Lite, VCI, OCP, Avalon, PLB, Tilelink, Wishbone or Custom protocol.

Octal SPI Master IIP IIP is supported natively in Verilog and VHDL

Note: Only mails from offical mail ID will be processed

Request Datasheet Request Evaluation
  • Full Octal SPI Master Functionality
  • Fast frequency support(Up to 133MHz)
  • Compliant to the SPI de-facto standard
  • Single, dual, quad and octal serial data lines
  • Software programmable transmission formats (CPOL and CPHA)
  • Up to 16 slaves supported under master control
  • Configurable SPI transfers
  • Fast sampling clock input for the SPI transfers
  • Copyright © SmartDV IP Solutions Private Limited
  • SPI Block Specs compliant
  • FIFOs used for transferring data (configurable depth)
  • Full duplex operation
  • LSB or MSB mode
  • 8-bit, 16-bit, 24-bit and 32-bit synchronous serial transmission
  • Software programmable SCLK rate
  • Supports DMA/HCI (Host controller Interface) mode of operation.
  • Interrupt control
  • Fully synthesizable
  • Static synchronous design
  • Positive edge clocking and no internal tri-states
  • Scan test ready
  • Simple interface allows easy connection to microprocessor/microcontroller devices
    • Single Site license option is provided to companies designing in a single site.
    • Multi Sites license option is provided to companies designing in multiple sites.
    • Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
    • Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
    • The OCTAL SPI MASTER interface is available in Source and netlist products.
    • The Source product is delivered in verilog.If needed, VHDL and SystemC can also be provided
    • Easy to use Verilog Test Environment with Verilog Testcases
    • Lint, CDC, Synthesis, Simulation Scripts with waiver files
    • IP-XACT RDL generated address map
    • Firmware code and linux driver package
    • Documentation contains User's Guide and Release notes.
