AC97 Controller IIP

AC'97 CONTROLLER interface provides full support for the AC'97 CONTROLLER synchronous serial interface, compatible with AC'97 2.2 specification. Through its AC'97 CONTROLLER compatibility, it provides a simple interface to a wide range of low-cost devices. AC'97 CONTROLLER IIP is proven in FPGA environment. The host interface of the AC'97 CONTROLLER can be simple interface or can be AMBA APB, AMBA AHB, AMBA AXI, VCI, OCP, Avalon, PLB, Tilelink, Wishbone or Custom protocol.

AC97 Controller IIP IIP is supported natively in Verilog and VHDL

Note: Only mails from offical mail ID will be processed

Request Datasheet Request Evaluation

Compliant with AC'97 2.2 specification
Supports AC'97 audio codec functionality
Supports variable and fixed sample rate support
Supports 16, 18 and 20 bit sample size support
Supports 6 output channel surround sound
Supports stereo input channel
Supports mono microphone channel
Supports external DMA engine
Fully synthesizable

Static synchronous design

Positive edge clocking and no internal tri-states

Scan test ready

Simple interface allows easy connection to microprocessor/microcontroller devices

Single site license option is provided to companies designing in a single site.
Multi sites license option is provided to companies designing in multiple sites.
Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.

The AC'97 CONTROLLER is available in Source and netlist products.
The Source product is delivered in plain text verilog.If needed VHDL,SystemC code can also be provided.
Easy to use Verilog Test Environment with Verilog Testcases
Lint, CDC, Synthesis, Simulation Scripts with waiver files
IP-XACT RDL generated address map
Firmware code and Linux driver package
Documentation contains User's Guide and Release notes.
