ETHERNET CYCLIC FEC IIP

ETHERNET CYCLIC FEC core is compliant with IEEE Standard 802.3.2018 Ethernet specification.Through its compatibility, it provides a simple interface to a wide range of low-cost devices. ETHERNET CYCLIC FEC IIP is proven in FPGA environment.The host interface of the ETHERNET CYCLIC FEC can be simple interface or can be AHB,AHB-Lite,APB,AXI,AXI-Lite,Tilelink,OCP,VCI,Avalon,PLB,Wishbone or Custom protocol.

ETHERNET CYCLIC FEC IIP IIP is supported natively in Verilog and VHDL

Note: Only mails from offical mail ID will be processed

Request Datasheet Request Evaluation
  • Compliant with ETHERNET specification.
  • Supports Full IEEE Standard 802.3.2018 Ethernet cyclic FEC functionality.
  • This FEC(Forward Error correction) methodology implements the (2112 , 2080) binary cyclic code is shortened from the cyclic Fire code (42987, 42955).
  • Supports FEC of 32 bits parity bits.
  • This FEC can correct up to 11-bit burst error.
  • Supports the pipelined mechanism for the error correction.
  • Single site license option is provided to companies designing in a single site.
  • Multi sites license option is provided to companies designing in multiple sites.
  • Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
  • Unlimited Designs,license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
  • The ETHERNET CYCLIC FEC interface is available in Source and netlist products.
  • The Source product is delivered in verilog. If needed VHDL, SystemC code can also be provided.
  • Easy to use Verilog Test Environment with Verilog Testcases.
  • Lint, CDC, Synthesis, Simulation Scripts with waiver files.
  • IP-XACT RDL generated address map.
  • Firmware code and Linux driver package.
  • Documentation contains User's Guide and Release notes.
