IEEE 1588 IIP

IEEE 1588 core is compliant with IEEE Standard 1588-2019 specification. Through its compatibility, it provides a simple interface to a wide range of low-cost devices. IEEE 1588 IIP is proven in FPGA environment. It can also supports a variety of host bus interfaces for easy adoption into any design architecture - AHB,AHB-Lite,APB,AXI,AXI-Lite,Tilelink,OCP,VCI,Avalon,PLB,Wishbone or custom buses

IEEE 1588 IIP IIP is supported natively in Verilog and VHDL

Note: Only mails from offical mail ID will be processed

Request Datasheet Request Evaluation
  • Compliant with IEEE Standard 1588-2019 specification
  • Supports for TSN required PTP as per IEEE 802.1AS
  • Configurable as PTP Master or PTP Slave
  • Supports both end to end and peer to peer delay mechanism
  • Generates timestamp based on Real time clock (high precision clock)
  • Generates Follow up message if it is a 2 step delay mechanism (when configured as Master)
  • Generates Delay Response message on reception of Delay Request message (when configured as Master)
  • Configurable for Delay Mechanism (End to end or peer to peer)
  • Formal mechanisms for message extensions (using TLV)
  • Transparent clocks
  • Options for redundancy and fault tolerance
  • New management capabilities and options
  • Optional unicast messaging (in addition to multicast)
  • Tight integration with SmartDV Ethernet MAC of all speeds
  • Fully synthesizable
  • Static synchronous design
  • Positive edge clocking and no internal tri-states
  • Scan test ready
  • Simple interface allows easy connection to Microprocessor/Microcontroller devices
    • Single site license option is provided to companies designing in a single site.
    • Multi sites license option is provided to companies designing in multiple sites.
    • Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
    • Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
    • The IEEE 1588 interface is available in Source and netlist products.
    • The Source product is delivered in plain text verilog.If needed VHDL,SystemC code can also be provided.
    • Easy to use Verilog Test Environment with Verilog Testcases
    • Lint, CDC, Synthesis, Simulation Scripts with waiver files
    • IP-XACT RDL generated address map
    • Firmware code and Linux driver package
    • Documentation contains User's Guide and Release notes.
