LDPC (1723,2048) IIP

LDPC (1723,2048) core is compliant with IEEE Standard 802.3.2018 Ethernet specification. Through its compatibility, it provides a simple interface to a wide range of low-cost devices. LDPC (1723,2048) IIP is proven in FPGA environment. The host interface of the LDPC (1723,2048) can be simple interface or can be AHB, AHB-Lite, APB, AXI, AXI-Lite, Tilelink, OCP, VCI, Avalon, PLB, Wishbone or custom buses.

LDPC (1723,2048) IIP IIP is supported natively in Verilog and VHDL

Note: Only mails from offical mail ID will be processed

Request Datasheet Request Evaluation
  • Compliant with IEEE Standard 802.3.2018 Ethernet specification.
  • Supports full LDPC functionality.
  • Supports the Lower density parity check (1723,2048).
  • Supports the parity generation of 325 bits.
  • Supports the bit locker mechanism.
  • Supports the parity checking.
  • Supports the syndrome calculation.
  • Supports the error correction mechanism.
  • Supports the pipe-lined mechanism for the error correction.
  • Single site license option is provided to companies designing in a single site.
  • Multi sites license option is provided to companies designing in multiple sites.
  • Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
  • Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
  • The LDPC (1723,2048) interface is available in Source and netlist products.
  • The Source product is delivered in plain text verilog.If needed VHDL,SystemC code can also be provided.
  • Easy to use Verilog Test Environment with Verilog Testcases
  • Lint, CDC, Synthesis, Simulation Scripts with waiver files
  • IP-XACT RDL generated address map
  • Firmware code and Linux driver package
  • Documentation contains User's Guide and Release notes.
