LPDDR3 Controller IIP

LPDDR3 interface provides full support for the LPDDR3 interface, compatible with JESD209-3,JESD209-3B and JESD209-3C specification and DFI-version 3.1 or higher specification Compliant. Through its LPDDR3 compatibility, it provides a simple interface to a wide range of low-cost devices. LPDDR3 IIP is proven in FPGA environment. The host interface of the LPDDR3 can be simple interface or can be AMBA AHB, AMBA AHB-Lite, AMBA APB, AMBA AXI, AMBA AXI-Lite, Tilelink, OCP, VCI, Avalon, PLB, Wishbone or Custom protocol.

LPDDR3 Controller IIP IIP is supported natively in Verilog and VHDL

Note: Only mails from offical mail ID will be processed

Request Datasheet Request Evaluation
  • Supports 100% of LPDDR3 protocol standard JESD209-3, JESD209-3B and JESD209-3C.
  • Compliant with DFI version 3.1 or higher Specification.
  • Supports all the LPDDR3 commands as per the specs.
  • Supports up to 16 AXI ports with data width upto 512 bits.
  • Supports controllable outstanding transactions for AXI write and read channels
  • Supports in port arbitration and multi port arbitration.
  • Supports user programmable page policy.
    • Closed page policy
    • Open page policy
  • Supports Error Checking and correction (ECC).
  • Supports retry on ECC error, with retry limit user controllable.
  • Supports high clock speeds in ASIC and FPGA.
  • Supports low latency for write and read path.
  • Supports reordering of transactions for higher performance.
  • Supports up to 32GB device density
  • Supports X16 and X32 devices.
  • Supports all data rates as per specification.
  • Supports for Programmable READ/WRITE Latency timings.
  • Supports for Burst sequence.
  • Supports for All Mode register programming.
  • Supports for write data mask and data strobe features.
  • Supports for Power Down features.
  • Supports for Deep Power Down features.
  • Supports for Write leveling.
  • Supports for ZQ calibration.
  • Supports for CA training and DQ calibration.
  • Supports for ODT (On-Die Termination features).
  • Fully synthesizable
  • Static synchronous design
  • Positive edge clocking and no internal tri-states
  • Scan test ready
  • Simple interface allows easy connection to Microprocessor/Microcontroller devices
    • Single site license option is provided to companies designing in a single site.
    • Multi sites license option is provided to companies designing in multiple sites.
    • Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
    • Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
    • The LPDDR3 interface is available in Source and netlist products.
    • The Source product is delivered in verilog. If needed VHDL, SystemC code can also be provided.
    • Easy to use Verilog Test Environment with Verilog Testcases.
    • Lint, CDC, Synthesis, Simulation Scripts with waiver files.
    • IP-XACT RDL generated address map.
    • Firmware code and Linux driver package.
    • Documentation contains User's Guide and Release notes.
