SPI Master IIP

SPI Master is full-featured,easy-to-use,synthesizable design,compatible with SPI Block Guide 4.01 Complient.Through its SPI Master compatibility, it provides a simple interface to a wide range of low-cost devices.SPI Master IIP is proven in FPGA environment. Designed to work with a wide variety of SPI bus variants, the core supports run-time control of several SPI protocol parameters. The host interface of the SPI Master can be AMBA APB, AMBA AHB, AMBA AHB-Lite, AMBA AXI, AMBA AXI-Lite, VCI, OCP, Avalon, PLB, Tilelink, Wishbone or Custom protocol.

SPI Master IIP IIP is supported natively in Verilog and VHDL

Note: Only mails from offical mail ID will be processed

Request Datasheet Request Evaluation
  • Compliant with SPI Block Guide 4.01 Standard
  • Complaint to TI and National Modes (Microwire)
  • Supports 3 wire and 4 wire operation
  • Supports DDR mode of operation
  • Single, dual, quad and octal serial data lines
  • In built DMA (Host Controller Interface) controller
  • Up to 16 slaves supported under master control
  • Supports multi master operation
  • Mode fault error flag with CPU interrupt capability
  • Serial clock with programmable polarity and phase
  • LSB or MSB mode
  • Supports flexible Serial clock generation
  • Full duplex and half duplex operation
  • Bi-directional mode
  • Supports any kind of SPI transactions to access any kind of SPI slave device
  • Fully synthesizable
  • Static synchronous design
  • Positive edge clocking and no internal tri-states
  • Scan test ready
  • Simple interface allows easy connection to microprocessor/microcontroller devices
    • Single Site license option is provided to companies designing in a single site.
    • Multi Sites license option is provided to companies designing in multiple sites.
    • Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
    • Unlimited Designs,license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
    • The SPI Master interface is available in Source and netlist products.
    • The Source product is delivered in verilog. If needed VHDL, SystemC code can also be provided.
    • Easy to use Verilog Test Environment with Verilog Testcases
    • Lint, CDC, Synthesis, Simulation Scripts with waiver files
    • IP-XACT RDL generated address map
    • Firmware code and Linux driver package
    • Documentation contains User's Guide and Release notes.
