TIMER IIP

TIMER is used to generate delays, signals with timing characteristics and measure the time between signal edges, compatible with standard protocol of TIMER specification. Through its TIMER compatibility, it provides a simple interface to a wide range of low-cost devices. TIMER IIP is proven in FPGA environment.The host interface of the TIMER can be simple interface or can be AMBA APB, AMBA AHB, AMBA AHB-Lite, AMBA AXI, AMBA AXI-Lite, VCI, OCP, Avalon, PLB, Tilelink, Wishbone or Custom protocol.

TIMER IIP IIP is supported natively in Verilog and VHDL

Note: Only mails from offical mail ID will be processed

Request Datasheet Request Evaluation
  • Supports 32 timers each of 32 bit.
  • Supports up/down counting modes.
  • Supports configurable counter width.
  • Supports to count a maximum value of 32'hFFFFFFFF in Generate and Capture mode.
  • Supports to count a maximum value of 64'hFFFFFFFFFFFFFFFF in Cascade mode.
  • Supports to generate a pulse after an interval.
  • Supports to generate a square waveform.
  • Supports to capture a value on trigger event.
  • Supports automatically reloading value.
  • Supports to hold count value.
  • Supports PWM mode.
  • Supports for halting and resuming timer.
  • Supports cascaded mode of operation.
  • Supports enabling and disabling of interrupts.
  • Fully synthesizable.
  • Static synchronous design.
  • Positive edge clocking and no internal tri-states.
  • Scan test ready.
  • Simple interface allows easy connection to microprocessor/microcontroller devices.
    • Single Site license option is provided to companies designing in a single site.
    • Multi Sites license option is provided to companies designing in multiple sites.
    • Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
    • Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
    • The TIMER interface is available in Source and netlist products.
    • The Source product is delivered in verilog. If needed VHDL, SystemC code can also be provided.
    • Easy to use Verilog Test Environment with Verilog Testcases.
    • Lint, CDC, Synthesis, Simulation Scripts with waiver files.
    • IP-XACT RDL generated address map.
    • Firmware code and Linux driver package.
    • Documentation contains User's Guide and Release notes.
